MS-9A29 fanless 3.5” system uses Intel Atom D2550, DDR3 SO-DIMM solution. Support HDMI, VGA, Dual Intel GbE LAN and Dual Mini-PCIe
FEATURES
MS-9A29 is powered by the latest Intel® Atom™ D2550 dual core processor with DDR3 memory up to 4GB for D2550 and the Intel® NM10 Express chipset. With integrated graphics and memory controller, the processor deliver graphics core rendering speeds 640 MHz while maintaining excellent power efficiency. In addition to higher speeds and low power consumption. The Intel® GMA 3650 graphics engine is built into the chipset to provide fast graphics performance, high visual quality, and flexible display options without the need for a separate graphics card. With a compact 3.5 inch system size, system developers get the freedom to design small embedded applications.
Specification
| Model Name |
MSI MS-9A29 |
| CPU |
D2550 |
| Chipset |
NM10 |
| Memory |
1* DDR3 SO-DIMM |
| Display |
VGA + HDMI |
| Ethernet |
2* Intel GbE LAN |
| Audio |
ALC887 |
| Storage |
1*SATA, 1*mSATA |
| Rear I/O |
LAN |
2 |
| VGA |
1 |
| HDMI |
1 |
| USB |
2 |
| Line out |
1 |
| DC Jack |
1 |
| Front panel |
USB |
4 |
| COM |
1 x RS-232/422/485 with powered 3 x RS-232 with powered |
| PWR LED |
1 |
| HDD LED |
1 |
| Antenna hole |
2 |
| PWR button |
1 x Jumper switch |
| Power-Type |
DC-in 12V |
|
